BreatheSafe Warranty

Built to Perform, Guaranteed to Last

How to Test the System

The below instructions give a general guide to cabin sealing, testing and commissioning BreatheSafe variable speed pressurisation units (clean cabin with HEPA vacuum).

1. Inspect the cabin and ensure all cover panels are in place and any holes are sealed with grommets, sealer, fit new door seals for used equipment, etc.

2. Sitting inside the cabin with the door open, turn on the ignition to power up the unit.

3. The pressuriser fan should power up to full speed, and the monitor should indicate 0 pressure (Allow ± 2 pascals wind gusts).

4. With the ignition on, close all doors and windows. If the cabin is adequately sealed, the monitor should indicate the set pressure of approximately 50 Pa (Pascals) or whichever preset has been chosen.

5. Once a pressure of approximately 50 Pa is confirmed, click the settings icon and “Max Pressure Test” to run the fan speed at max speed. The display will indicate “Max Pressure Test” before showing the maximum cabin pressure.

6. InPress with Auto Pressure Control (5400 RPM), the cabin pressure should be above 250 Pa (The minimum is 250 pascals, tested with a new TLF700EN HEPA filter). A result of 500 pascals is ideal.

7. If the above pressure is not achieved, leave the unit on full speed and investigate for external leaks outside the cabin: e.g., A/C outlets, drains, window & door seals, locks & hinges, etc.

8. If necessary, with the ignition on, controller on ‘Max Pressure Test’, A/C blower OFF and all doors and windows closed, set off a smoke emitter inside the cabin (SWP attached).

9. Locate any air leaks around the cabin and re-test. If silicone sealant or similar is used, allow it to dry before retesting, as even slamming the door could push the seal back out.

10. Continue the sealing and testing procedure as above until a satisfactory outcome is achieved. Fill out the record below and attach photo evidence of the maximum pressure result to register for warranty.

Support Videos

System with OnGuard Controller

(Touchscreen)

System with OnGuard Controller

(Legacy Non-touchscreen)

System with InPress Controller

Having Issues?

Contact us today and we’ll get back to you ASAP. We pride ourselves on quality workmanship and products, and will help troubleshoot and problem-solve any issues.

Warranty Claims

Make your claim using the form below. We will get back to you shortly.


Warranty Information

Express Warranty

All BreatheSafe products carry a warranty against defects in materials or workmanship, provided the defects are not from factors outside BreatheSafe’s control (including neglect, lack of maintenance, improper installation or operation, unauthorised servicing, repair, etc.). BreatheSafe will replace goods defective in material or workmanship at our Queensland factory or designated branch*. All parts deemed as failed or faulty must be returned to BreatheSafe for evaluation unless otherwise stated in writing.

* Note- Systems must be installed and commissioned as per BreatheSafe installation and commissioning instructions. Once commissioned, the online commissioning sheet must be filled in, which will then extend the components' warranty as follows.

The system must be serviced and maintained correctly, and by trained and qualified personnel. This includes BreatheSafe technicians, qualified automotive air-conditioning technicians, or qualified auto electricians.

Warranty period – Standard

  • 1 year or 10,000 hours (whichever occurs first).
  • Controllers – 1 year with no extended warranty option.

Warranty Period Extension when commissioning documents are registered online within 28 days of installation
An extended warranty is only offered if commissioning maximum pressure test reaches at least 250Pa.

  • Brushless motor fixed speed 2 years, or 10,000 hours (whichever occurs first).
  • Variable speed brushless motor 15,000 hours, or 3 years** (whichever occurs first).

** Must be supplied with a variable speed pressure controller, data download required for 3-year warranty option.

Link to online Commissioning and Extended Warranty Registration form

https://www.breathe-safe.com.au/commission/

What is not covered under Express Warranty?

  • Failures due to incorrect application.
  • Damage resulting from neglect, misuse, lack of maintenance, improper installation, or operation, improper or abnormal use, accidental or unauthorised servicing repair.
  • Failures due to parts not sold or approved by BreatheSafe.
  • Failures from any other cause not directly related to a defect in material or workmanship.

This Express Warranty is VOID if the product is altered, modified, or used in a manner it was not designed for, including unauthorised repairs, or using maintenance and repair parts other than those supplied by BreatheSafe.

BreatheSafe responsibilities

  • If there is a defect in material or workmanship not caused by the excluded failures during the warranty period, BreatheSafe will either replace the defective goods at our Queensland factory or a designated branch. *
  • Alternatively, BreatheSafe may elect to provide new replacement parts, BreatheSafe-approved repair parts or assembled components needed to repair the defect.
  • BreatheSafe reserves the right to provide a refund of the purchase price in lieu of replacement or repair at BreatheSafe’s discretion.
  • The replacement or repaired product will be sent to you freight prepaid by the customer or made available for pick-up on site.

Users Responsibilities

  • The customer should ensure that the system is maintained according to BreatheSafe service requirements, and only authorised parts must be used to service and maintain BreatheSafe systems.
  • In the event of a suspected warranty claim, BreatheSafe should be contacted in the first instance to arrange the repair or to assist with diagnosis. Claims should be made within one week of the repair.
  • After contacting BreatheSafe, you may be required to deliver or send the parts to BreatheSafe’s Queensland factory or designated branch. *

Link to online Warranty claim form

https://www.breathe-safe.com.au/warranty/

Exclusion and Limitations on Damages and Remedies

  • This warranty is provided in lieu of all other warranties, written or oral, whether express by affirmation, promise, description, drawing, model, or sample.
  • To the extent allowed by law, all warranties other than this warranty, whether express or implied, including implied warranties of fitness for a particular purpose, are disclaimed.
  • The maximum liability of BreatheSafe under this warranty shall not exceed the original purchase price of the product.
  • Interference with the equipment by abuse, or by operating the equipment at ambient temperatures or with electrical power characteristics outside the ranges indicated in our specification, shall be excluded from this warranty, as shall consequential damages.
  • Excluded from any express warranty are costs incurred in relation to service outside our factory or our designated service branch, including travelling time, waiting time, transport costs, and mechanical and overtime payments required.

ACL required text for goods warranties

As per Australian Consumer Law:

You are entitled to choose a refund or replacement for major failures with goods. If a failure with the goods or a service does not amount to a major failure, you are entitled to have the failure rectified in a reasonable time. If this is not done, you are entitled to a refund for the goods and to cancel the contract for the service and obtain a refund of any unused portion.



*This express warranty gives you specific legal rights, and you may also have other rights that vary from country to country.*
